Tungsten

Tungsten carbide is a hardmetal: very hard tungsten carbide grains held together by a binder such as cobalt. In watchmaking its main role was to make scratchproof cases, and Rado built its early reputation on it with the DiaStar of 1962. The same hardness that resists scratches makes the material difficult to shape and limits its toughness, which is why tungsten stays a specialist material.

A vintage Rado DiaStar, the tungsten carbide hardmetal watch from 1962

A Rado DiaStar, the 1962 hardmetal original. Photo: Wikimedia Commons, CC BY-SA.

How it works

Tungsten carbide, WC, is a compound of tungsten and carbon with very strong covalent bonds, and it is one of the hardest common materials, about 2,600 HV. Alone it is brittle and hard to shape, so it is made as a cemented carbide. Tungsten carbide powder is mixed with a metal binder, usually cobalt or nickel at 6 to 20 percent by weight, pressed to shape and sintered. At the sintering temperature the binder melts and wets the grains, pulling them together and filling the gaps, so on cooling the carbide grains are bonded in a tough metal matrix. The hard grains resist scratching, and the binder absorbs energy so that a crack does not run straight through. Less binder makes the material harder and more brittle, and more makes it tougher and softer. Because the form is sintered, a case is made as a near-net-shape blank and finished by grinding with diamond.

The density of tungsten carbide grades is 13.5 to 15.1 grams per cubic centimeter, depending on binder content and manufacturing method, which is heavier than steel (7.9) but below the 19.25 of tungsten metal itself.

Tungsten carbide cutting inserts used in industrial machining

Tungsten carbide cutting inserts. The same hardmetal family Rado borrowed from industry. Photo: Wikimedia Commons, CC BY-SA.

A hardmetal case

The DiaStar, introduced in 1962, was the first watch with a hardmetal case. Hardmetal is a tungsten carbide alloy nearly as hard as sapphire, and Rado marketed the DiaStar as the world’s first scratch-proof watch. The original was an automatic with a cushion-shaped case and an integrated bracelet, designed by Raymond Studer, and its dial was protected by a faceted sapphire crystal, a Rado hallmark.

Rado after the DiaStar

Rado kept moving up the hardness scale. The V10K, a hardmetal case coated with synthetic diamond, was rated at 10,000 on the Vickers scale, the top of the scale where only diamond sits, and it launched in 2002 according to one retailer. A separate description says the diamonds are grown in a furnace that recreates the pressure of Jupiter’s atmosphere.

Hublot’s Magic Gold

Hublot approached the same idea from the other direction. Magic Gold is an 18k gold alloy made by filling porous boron carbide, a very hard ceramic, with 24k gold. Hublot compresses boron carbide into case-like shapes, then infuses it with gold under inert gas at very high pressure and temperature. It is the inverse of cemented carbide: there a hard grain is held by a metal binder, here a porous ceramic skeleton is filled with metal. The result can only be machined with diamond-tipped tools, lasers or ultrasonic cutters, and it measures about 1,000 Vickers.
