Precious & Exotic Materials

Most watches are steel, gold, titanium or ceramic. A smaller shelf holds materials chosen for their pattern and their story rather than their performance: slices of meteorite, pattern-welded steel, layered Japanese metalwork and wood. Each one brings a visual effect that no standard case metal can match, and each comes with a practical weakness that explains why it stays at the margins.

An etched slice of the Kossuth iron meteorite showing the Widmanstatten pattern

An etched slice of an iron meteorite, showing the Widmanstätten pattern. No two dials cut from it look alike. Photo: James St. John, Wikimedia Commons, CC BY-SA.

Meteorite

Most meteorite watch dials come from two large, well-known falls: the Gibeon meteorite, found in Namibia, and the Muonionalusta meteorite, which landed in Sweden. Fragments of both were scattered over wide areas, and some pieces are large. Both are iron-nickel alloys. Cutting a thin slice, polishing it and etching it with a chemical such as nitric acid brings out the Widmanstätten pattern, a crisscrossing crystalline structure.

The pattern has a physical cause. Iron-nickel from a molten asteroid core cools extremely slowly, over millions of years. As it cools, a low-nickel phase (kamacite) separates from a high-nickel phase (taenite) in plates along particular crystal planes, and the two etch at different rates in acid, which is why the pattern appears. It cannot be made by any human process, because the cooling rate is slower than any furnace.

Meteorite is usually a dial material because dials are small and thin, and a brand can use a little material without depleting the supply. The material is also brittle, hard to shape and prone to oxidation, which watchmakers counter with protective coatings or finishes. Rolex has offered meteorite dials on the Day-Date, GMT-Master II and Daytona, often in platinum or gold. William Henry’s Legacy Meteorite pairs a Gibeon meteorite dial with a case in Moku-Ti, a forged titanium made from 90 layers of four aerospace-grade alloys, in a limited edition of 250 priced at US$8,995.

Damascus steel

The original Damascus steel was a cast material whose technique was largely lost in the 17th century. What watch brands sell under the name is pattern-welded steel, made by welding several steel alloys together and drawing and folding them into a single billet. Acid etching then exaggerates the differences between the layers, since each reacts to the acid differently, which produces the varying shades. Each fold doubles the layer count, so a few folds give dozens of layers.

Sinn’s 1800 S Damaszener, limited to 100 pieces, is a clear example. Balbach Damast, a specialist near Frankfurt, forge-welded two grades of stainless steel, and the case and dial are a single forged piece, so the pattern runs continuously from dial to flanks. Sinn applies its Tegiment surface hardening to improve scratch resistance. Schofield’s Obscura is a 41 mm, 15 mm thick case with 200 m of water resistance.

A pattern-welded damascus steel blade showing the layered pattern

A pattern-welded damascus blade. Watch cases use the same layered-steel technique. Photo: Wikimedia Commons, CC BY-SA.

Mokume-gane and shibuchi

Mokume-gane, wood-grain metal, is a Japanese technique dating to the Edo period (about 1650 to 1868). The smith Denbei Shoami, working in Akita, stacked gold, silver, copper, shakudo and shibuchi, heated the stack just below its melting points so the layers fused, then forged and carved it to reveal the pattern. It began as a decoration for sword fittings. The bonding is diffusion bonding: atoms migrate across the contact between clean, hot sheets until they form a continuous solid, without melting, and cutting through the layers at an angle exposes the pattern.

Shibuchi is one of the traditional alloys layered in mokume-gane: roughly 75 percent copper and 25 percent silver, with a patina that turns a soft dove grey. In watches, Credor’s 45th anniversary model of 2019, limited to 35 pieces, carried a dial made with mokume-gane by Mokumeganeya, a design the maker says evokes golden rice fields moving in the wind.

Wood

Wood is the lightest and warmest of the exotic materials, and the least durable. It is hygroscopic: the cell walls take up and release water with the humidity of the air, and the wood swells and shrinks, most across the grain. Wooden watch makers note that most wooden watches are not waterproof, and that humidity and temperature changes can cause slight warping or surface marks, and that wood is more delicate than metal, so it suits everyday wear better than sport. Some brands work around this by housing the movement in a stainless steel case inside the wooden one.
